Technical Specifications
Nexperia PSMN3R0-60PS,127 technical specifications, attributes, and parameters.
| Supply Chain | |
|---|---|
| Lifecycle Status | Production (Last Updated: 1 day ago) |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY (Last Updated: 1 day ago) |
| Physical | |
| Case/Package | SOT |
| Contact Plating | Tin |
| Number of Pins | 3 |
| Technical | |
| Continuous Drain Current (ID) | 100 A |
| Drain to Source Breakdown Voltage | 60 V |
| Drain to Source Resistance | 2.4 mΩ |
| Drain to Source Voltage (Vdss) | 60 V |
| Element Configuration | Single |
| Fall Time | 22 ns |
| Gate to Source Voltage (Vgs) | 20 V |
| Input Capacitance | 8.079 nF |
| Max Dual Supply Voltage | 60 V |
| Max Operating Temperature | 175 °C |
| Max Power Dissipation | 306 W |
| Min Operating Temperature | -55 °C |
| Number of Elements | 1 |
| Power Dissipation | 306 W |
| Rds On Max | 3 mΩ |
| Rise Time | 26 ns |
| Turn-Off Delay Time | 77 ns |
| Turn-On Delay Time | 31 ns |
| Compliance | |
| Radiation Hardening | No |
| RoHS | Compliant |
